| Frame size current (A) | 125 | 160 | 250 | 400 | 630 | 800 | 1000 | 1250 | |||||||||||||||
| Model | NS05-F-125 | NS05-F-160 | NS05-F-250 | NS05-F-400 | NS05-F-630 | NS05-F-800 | NS05-F-1000 | NS05-F-1250 | |||||||||||||||
| Current class model (ICU/ICS) | S | H | S | M | H | S | M | H | S | M | H | S | M | H | S | M | H | M | H | ||||
| Pole number | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | |||||||||||||||
| Rated current(A) | 10, 16, 20, 32, 40, 50, 63, 80, 100, 125 |
10, 16, 20, 32, 40, 50, 63, 80, 100, 125, 140, 160 |
100, 125, 140, 160, 180 200, 225, 250 |
250, 315, 350, 400 500, 630 |
250, 315, 350, 400 500, 630 |
500, 630, 700, 800 | 630,800 ,1000 | 800,1000,1250 | |||||||||||||||
| Rated voltage(V) | AC400V | AC400V | AC400V | AC400V | AC400V | AC400V | AC400V | AC400V | |||||||||||||||
| Rated insulation voltage (V) |
AC1000V | AC1000V | AC1000V | AC1000V | AC1000V | AC1000V | AC1000V | AC1000V | |||||||||||||||
| Short-circuit breaking capacity(KA)Icu/Ics |
AC 400V |
25/15 | 25/18 | 25/18 | 36/18 | 50/35 | 25/18 | 36/18 | 50/35 | 25/18 | 36/18 | 50/35 | 25/18 | 36/18 | 50/35 | 50/35 | 65/42 | 70/70 | 65/65 | 70/70 | |||
| Operating cycle number |
ON | 6000 | 3000 | 3000 | 2000 | 2000 | 1500 | 1500 | 1500 | ||||||||||||||
| OFF | 9000 | 7000 | 7000 | 4000 | 4000 | 4000 | 4000 | 4000 | |||||||||||||||
|
3P | 75 130 68 90 |
90 155 68 90 |
90 155 68 90 |
90 155 88 115 |
105 165 68 92 |
105 165 68 92 |
105 165 88 115 |
140 257 103 155 |
140 257 103 155 |
210 275 103 155 |
210 275 103 155 |
210 275 103 156 |
||||||||||
| 4P | 100 130 68 90 |
120 155 68 90 |
120 155 68 90 |
120 155 88 115 |
140 165 68 92 |
140 165 68 92 |
140 165 88 115 |
184 257 103 155 |
184 257 103 155 |
280 275 103 155 |
280 275 103 155 |
280 275 103 156 |
|||||||||||
| Weight(kg) | 3P | 0/55 | 0/65 | 1/1 | 1/2 | 1/5 | 1/7 | 5/5 | 5/7 | 9/5 | 8/5 | 9 | |||||||||||
| 4P | 0/65 | 0/8 | 1/4 | 1/5 | 1/9 | 2/1 | 7.0 | 7/5 | 12/5 | 11/5 | 12 | ||||||||||||
| Electric operating device(MD) |
l | l | l | l | l | l | l | l | |||||||||||||||
| External driving operating handle |
l | l | l | l | l | l | l | l | |||||||||||||||
