| NS22-FJ125A-3P | |||
| CB/CE/RoHS | CERTIFICATION | ||
| MATERIAL | |||
| 74x99x51 | Size(mm) | ||
| Zinc-Coated Steel | Screw | ||
| Tin-Coated Brass | Conductor | ||
| PA66/V-0 | Housing | ||
| PC | Cover | ||
| ELECTRICAL DATA | |||
| IEC 60947-7-1 | Standards | ||
| 690 | Voltage(V) | ||
| 125 | Current(A) | ||
| 4.4 | Icw(KA) | ||
| 30 | Ipk(KA) | ||
| WIRING DATA | |||
| C | B | A | Input |
| 3×2 | 3×5 | 3×1 | Connection Points |
| 1.5 | 0.8 | 1.5 | Torque(N.m) |
| 7 | 5 | 9 | Diameter(mm) |
| 4~16 | 1.5~6 | 6~35 | Metric Wire(mm²) |
| 11~5 | 15~9 | 9~2 | Imperial Wire(AWG) |
| C | B | A | Output |
| x6 | x4 | x1 | Connection Points |
| 1.5 | 0.8 | 1.5 | Torque(N.m) |
| 7 | 5 | 9 | Diameter(mm) |
| 4~16 | 1.5~6 | 6~35 | Metric Wire(mm²) |
| 4~16 | 15~9 | 9~2 | Imperial Wire(AWG) |
